Reactive Power Control in Power Systems

Understanding reactive power control, sourcing, and regulation to keep voltage stable under all operating conditions.

Introduction to Reactive Power Control

Every alternating current power system carries two kinds of power. Active power performs useful work, driving motors, heating elements, and illuminating lamps. Reactive power, on the other hand, does no net work but is essential for establishing and sustaining the electromagnetic fields that make transformers, motors, and transmission lines function. Without an adequate supply of reactive power at the right locations, voltages sag, equipment loses efficiency, and in extreme cases, the entire system can collapse.

Reactive power control is therefore a fundamental responsibility of power system operators. Unlike active power, which can be transmitted efficiently over long distances, reactive power does not travel well. It must be generated and consumed locally, close to where inductive loads and capacitive elements demand it. This locality gives reactive power control its characteristic flavour: it is a distributed problem, requiring coordinated action from generators, transformers, capacitor banks, reactors, and modern power electronic compensators spread throughout the network.

Reactive Power Requirement in Steady State

Under normal operating conditions, the network draws reactive power from many sources simultaneously. Inductive consumers such as induction motors, arc furnaces, discharge lighting, and lightly loaded transformers absorb lagging reactive power. Transmission lines behave in a more nuanced fashion: at light load they generate reactive power due to their line-to-ground capacitance, but at heavy loading they consume it because the series inductance dominates. The load level at which a line neither absorbs nor delivers reactive power is called its surge impedance loading.

The steady-state requirement is thus dictated by three broad factors. The first is the composition of the load, which typically operates at a power factor between 0.80 and 0.95 lagging. The second is the loading condition of transmission lines and transformers. The third is the voltage profile the operator wishes to maintain, since higher operating voltages reduce line current for a given active power transfer and consequently reduce reactive losses.

To meet this demand, operators plan reactive power resources so that at every major bus, the voltage remains within a narrow band, usually between 0.95 and 1.05 per unit. Achieving this profile requires reactive compensation devices distributed across substations and generation stations, each one sized and switched according to the seasonal and daily variation of load.

Sources of Reactive Power

Reactive power can be supplied or absorbed by a variety of devices, each with its own characteristics. Synchronous generators are the most flexible source. By adjusting the field excitation, an operator can make a generator deliver leading reactive power (overexcited) or absorb it (underexcited). Because generators are already installed and equipped with automatic voltage regulators, they form the first line of reactive support.

Shunt capacitors are the most common dedicated compensation devices. They supply reactive power in fixed steps and are inexpensive, but they suffer from an inherent weakness: the reactive power they deliver is proportional to the square of the terminal voltage, meaning their support falls off precisely when the system needs it most, during voltage depressions.

Shunt reactors do the opposite. They absorb reactive power and are used on long, lightly loaded transmission lines to counteract the Ferranti effect, in which the receiving-end voltage rises above the sending-end voltage. Synchronous condensers are essentially unloaded synchronous machines that can smoothly vary their reactive output through excitation control. They provide inertia and short-circuit contribution as an added benefit, though their rotating nature makes them more expensive to maintain.

Static VAR System

A Static VAR System, or SVS, is a shunt-connected power electronic device that provides rapid, continuous control of reactive power without any rotating parts. It combines thyristor-controlled reactors and switched capacitor banks in a single coordinated package. By varying the firing angle of the thyristors that gate the reactors, the effective inductive current is continuously adjusted from full conduction to nearly zero. The parallel capacitor banks, switched in or out either mechanically or by thyristors, provide the bulk capacitive support.

The most widely used arrangement is the combination of a Thyristor Controlled Reactor (TCR) with a Thyristor Switched Capacitor (TSC). The TCR provides smoothly variable inductive current, while the TSC contributes stepped capacitive current. When combined, the net reactive output can be varied continuously from full absorption to full generation, all within a few milliseconds.

An SVS is controlled by a closed-loop regulator that senses the bus voltage and adjusts the thyristor firing to maintain it at a set point. Because the response is essentially electronic, an SVS can act within one or two power frequency cycles, making it invaluable at buses feeding fluctuating loads such as electric arc furnaces, rolling mills, and long transmission corridors where voltage flicker or steady-state instability would otherwise limit the transferable power.

Reactive Power Control During Transients

Steady-state control is only half the story. During transient events, such as line faults, sudden load changes, generator tripping, or switching operations, the reactive power balance can be violently disturbed. A fault close to a generator, for instance, may cause severe voltage collapse followed by an overvoltage swing once the fault is cleared. If reactive support is not restored quickly, voltage stability can be lost within seconds.

During transients, the fastest sources of reactive power take priority. Automatic voltage regulators on generators, aided by ceiling excitation and power system stabilizers, respond within a few cycles to boost field current and inject reactive power. Static VAR systems and STATCOMs, being purely electronic, respond even faster and are often the difference between a system riding through a disturbance and one that collapses.

Mechanically switched capacitors and reactors are too slow to act during the first transient swing but play an important role in the seconds and minutes that follow, when the system is settling into a new operating point. Coordinated protection and control schemes ensure that these devices switch in the correct sequence, restoring the voltage profile without introducing new oscillations.

Modern wide-area monitoring systems, which sample voltage and current phasors from across the network many times per second, allow operators to observe reactive power flows in real time and to detect emerging problems before they become critical. Combined with fast electronic compensators, they make it possible to operate transmission systems closer to their thermal and stability limits than ever before, delivering more power over the same infrastructure while maintaining the tight voltage discipline that reliable electricity supply demands.
